Garmin VHF 115i DSC VHF Radio With Internal GPS

Easy to install and use, just plug and play to compatible Garmin chartplotters and MFDs via the NMEA 2000 network. VHF 115i provides standard Class D DSC functionality (distress calling and direct calling with user-programmed MMSI). The radio is preprogrammed with international marine channels. It's also NMEA 0183 compatible.

• Fixed-mount with plug and play via the NMEA 2000^® network
• Standard Class D Digital Selective Calling (DSC) functionality (distress calling and direct calling with user-programmed MMSI)
• Preprogrammed with international marine channels
• In case of trouble, DSC may improve your chances of a rapid rescue
• 25-watt transmit power with built-in GPS
• Frequency bands: preprogrammed with international marine channels
• Speaker microphone audio power: 94 dBA
• Operating voltage: 12.0 VDC (volts of direct current)
• Current drain — standby: 350 mA; receive: 600 mA; transmit: 6.0 A at high power (25 watts); 2.0 A at low power (1 watt)
• Designed to complement the latest GPSMAP^® 7x2/9x2, GPMAP 10x2/12x2, GPSMAP 7400/7600 and GPSMAP 8400/8600 chartplotters and MFDs

Specifications

• Unit dimensions, HxWxD: 8.5 x 17.0 x 14.6 cm
• Weight: 1.24 kg
• Water rating: IPX7
• Temperature range: Operating from -15°C to 70°C; Storage from -20°C to 70°C
• Compass-safe distance: 70 cm
• NMEA 2000: Yes
• NMEA 0183: Yes
• Digital selective calling: Class D
• Frequency bands: All USA, Canadian and International marine channels; 10 NOAA weather channels
• Operating voltage: 12.0 Vdc
• Current draw: Standby 350 mA; Receive 600 mA; Transmit from 2.0 A to 6.0 A (from 1 W to 25 W)
• Frequency range: 156.050 MHz to 163.275 MHz (including WX channels)
• External speaker impedance: 4 Ω
• Antenna connector: S0-239 (50 Ω)
• Maximum antenna gain: 9 dBi

In The box

• VHF 115i marine radio
• Bail mount with knobs and mounting hardware
• Protective cover
• Trim ring snap cover
• Flush mount gasket
• Power cable
• Documentation
